High Speed rubber strip cutting machine,China rubber strip cutting machine Manufacturers,Suppliers,Factory Price -Pegedeflashing.com

Advanced Rubber Sheet Cutting Machine PG-HA-600

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Rubber Strip Cutting Machine Advanced Type Model PG-HA-600 PG-HA-800 PG-HA-1000 Size 1350*1300*1490 1350*1500*1490 1350*1700*1490 Weight 600kg 680kg 760kg Cutting Direction Horizontal Horizontal Horizontal Cutting width ≤580mm ≤800mm ≤1000mm Cutting Length 0.1-1000mm 0.1-1000mm 0.1-1000mm Cutting Thickness 0~25mm 0~25mm 0~25mm Max Precision 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. Blade Material Tungsten Steel W18 Tungsten Steel W18 Tungsten Steel W18 Feeding Mode Servo motor Servo motor Servo motor Cut Speed ≤80/min ≤80/min ≤80/min Power supply 4kw 3ph 380v 4kw 3ph 380v 5.5kw 3ph 380v Speed Control PLC& Inverter PLC& Inverter PLC& Inverter Operation Mode 7-inch Touch Screen 7-inch Touch Screen 7-inch Touch Screen

Tags : Rubber Strip Cutter rubber strip cutting machine rubber cutting machine manufacutures rubber cutter rubber sheet cutting machine rubber sheet cutter
Read More
Advanced Rubber Sheet Cutting Machine PG-HA-800

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Rubber Strip Cutting Machine Advanced Type Model PG-HA-600 PG-HA-800 PG-HA-1000 Size 1350*1300*1490 1350*1500*1490 1350*1700*1490 Weight 600kg 680kg 760kg Cutting Direction Horizontal Horizontal Horizontal Cutting width ≤580mm ≤800mm ≤1000mm Cutting Length 0.1-1000mm 0.1-1000mm 0.1-1000mm Cutting Thickness 0~25mm 0~25mm 0~25mm Max Precision 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. Blade Material Tungsten Steel W18 Tungsten Steel W18 Tungsten Steel W18 Feeding Mode Servo motor Servo motor Servo motor Cut Speed ≤80/min ≤80/min ≤80/min Power supply 4kw 3ph 380v 4kw 3ph 380v 5.5kw 3ph 380v Speed Control PLC& Inverter PLC& Inverter PLC& Inverter Operation Mode 7-inch Touch Screen 7-inch Touch Screen 7-inch Touch Screen

Tags : Rubber Strip Cutter rubber strip cutting machine rubber cutting machine manufacutures rubber cutter rubber sheet cutting machine rubber sheet cutter
Read More
Advanced Rubber Strip Cutter PG-HA-1000

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Rubber Strip Cutting Machine Advanced Type Model PG-HA-600 PG-HA-800 PG-HA-1000 Size 1350*1300*1490 1350*1500*1490 1350*1700*1490 Weight 600kg 680kg 760kg Cutting Direction Horizontal Horizontal Horizontal Cutting width ≤580mm ≤800mm ≤1000mm Cutting Length 0.1-1000mm 0.1-1000mm 0.1-1000mm Cutting Thickness 0~25mm 0~25mm 0~25mm Max Precision 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. 0.1mm or 0.1g* *Strip thickness should be consistent. Blade Material Tungsten Steel W18 Tungsten Steel W18 Tungsten Steel W18 Feeding Mode Servo motor Servo motor Servo motor Cut Speed ≤80/min ≤80/min ≤80/min Power supply 4kw 3ph 380v 4kw 3ph 380v 5.5kw 3ph 380v Speed Control PLC& Inverter PLC& Inverter PLC& Inverter Operation Mode 7-inch Touch Screen 7-inch Touch Screen 7-inch Touch Screen

Tags : Rubber Strip Cutter rubber strip cutting machine rubber cutting machine manufacutures rubber cutter rubber sheet cutting machine rubber sheet cutter
Read More
Standard Rubber Strip Cutting Machine PG-H-800

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Rubber Strip Cutting Machine Standard Type Model PG-H-600 PG-H-800 PG-H-1000 Size 1170*1300*1400 1170*1500*1400 1170*1700*1400 Weight 400kg 450kg 500kg Cutting Direction Horizontal Horizontal Horizontal Cutting width ≤580mm ≤800mm ≤1000mm Cutting Length 0.1-1000mm 0.1-1000mm 0.1-1000mm Cutting Thickness 0~12mm 0~12mm  0~12mm  Precision 0.2mm or 0.3g 0.2mm or 0.3g 0.2mm or 0.3g Blade material CR12Mov CR12Mov CR12Mov Feeding mode Stepper motor Stepper motor Stepper motor Cut Speed ≤70/min ≤70/min ≤70/min Power supply 2kw 3ph 380v 3kw 3ph 380v 4kw 3ph 380v Speed Control Industrial Control Board Industrial Control Board Industrial Control Board Operation Mode 7-inch Touch Screen 7-inch Touch Screen 7-inch Touch Screen

Tags : Rubber Strip Cutter strip cutter rubber cutter rubber cutting machine rubber strip cutting machine rubber sheet cutting machine
Read More
Standard Rubber Strip Cutting Machine PG-H-600

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Rubber Strip Cutting Machine Standard Type Model PG-H-600 PG-H-800 PG-H-1000 Size 1170*1300*1400 1170*1500*1400 1170*1700*1400 Weight 400kg 450kg 500kg Cutting Direction Horizontal Horizontal Horizontal Cutting width ≤580mm ≤800mm ≤1000mm Cutting Length 0.1-1000mm 0.1-1000mm 0.1-1000mm Cutting Thickness 0~12mm 0~12mm  0~12mm  Precision 0.2mm or 0.3g 0.2mm or 0.3g 0.2mm or 0.3g Blade material CR12Mov CR12Mov CR12Mov Feeding mode Stepper motor Stepper motor Stepper motor Cut Speed ≤70/min ≤70/min ≤70/min Power supply 2kw 3ph 380v 3kw 3ph 380v 4kw 3ph 380v Speed Control Industrial Control Board Industrial Control Board Industrial Control Board Operation Mode 7-inch Touch Screen 7-inch Touch Screen 7-inch Touch Screen

Tags : Rubber Strip Cutter strip cutter rubber cutter rubber cutting machine rubber strip cutting machine rubber sheet cutting machine
Read More
Auto Pneumatic Weighing Rubber Cutting Machine PG-AW-600

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Pneumatic Auto Weighing Rubber Strip Cutter Model PG-AW-600 PG-AW-800 Type Pneumatic Drive Pneumatic Drive Power supply 2.2kw 1ph 220V 50/60Hz 2.2kw 1ph 220V 50/60Hz Size 1030*899*1580 1030*1100*1580 Weight 320kg 400kg Cutting Direction Horizontal Horizontal Cutting width ≤580mm ≤800mm Cutting Length 0.1-1000mm 0.1-1000mm Cutting Thickness 0~10mm 0~10mm Max Precision 0.1mm or 0.2g* *Strip thickness should be consistent. 0.1mm or 0.2g* *Strip thickness should be consistent. Blade Material Cr12 Mov Vacuum Heat Cr12 Mov Vacuum Heat Feeding Mode Stepper Motor Stepper Motor Cut Speed 0-12cuts/min 0-12cuts/min Speed Control PLC PLC Operation Mode 7-inch Touch Screen 7-inch Touch Screen

Tags : auto rubber strip cutter by weight rubber cutter rubber cutting machine rubber strip cutting machine rubber sheet cutting
Read More
Pneumatic Auto Weighing Rubber Cutting Machine PG-AW-800

The Pege Rubber Strip Cutter is primarily used for cutting raw material into precision length or weight strips and then load into multi-cavity moulds and is commonly used to produce strips to make moulds for the production of various rubber components.   Pneumatic Auto Weighing Rubber Strip Cutter Model PG-AW-600 PG-AW-800 Type Pneumatic Drive Pneumatic Drive Power supply 2.2kw 1ph 220V 50/60Hz 2.2kw 1ph 220V 50/60Hz Size 1030*899*1580 1030*1100*1580 Weight 320kg 400kg Cutting Direction Horizontal Horizontal Cutting width ≤580mm ≤800mm Cutting Length 0.1-1000mm 0.1-1000mm Cutting Thickness 0~10mm 0~10mm Max Precision 0.1mm or 0.2g* *Strip thickness should be consistent. 0.1mm or 0.2g* *Strip thickness should be consistent. Blade Material Cr12 Mov Vacuum Heat Cr12 Mov Vacuum Heat Feeding Mode Stepper Motor Stepper Motor Cut Speed 0-12cuts/min 0-12cuts/min Speed Control PLC PLC Operation Mode 7-inch Touch Screen 7-inch Touch Screen

Tags : auto rubber strip cutter by weight rubber cutter rubber cutting machine rubber strip cutting machine rubber sheet cutting
